＠：经销品牌>>DORMER>>DORMER螺纹铣刀>>J220-英国多马DORMER螺纹铣刀

DORMER

J220

MF标准螺纹铣刀,螺旋角度10°
≥ P(mm) d1(mm) l2(mm) l1(mm) d2(mm) z 订货号 　 RMB未税面价
M6 0.50 4.80 10.0 57 6 3 J2204.8X.5 　 1,230.00
M8 0.75 6.00 12.0 57 6 3 J2206.0X.75 　 1,605.00
M8 1.00 6.00 12.0 57 6 3 J2206.0X1.0 　 1,605.00
M10 1.00 8.00 16.0 63 8 4 J2208.0X1.0 　 1,855.00
M12 1.00 10.00 20.0 72 10 4 J22010.0X1.0 　 2,440.00
M12 1.50 10.00 20.0 72 10 4 J22010.0X1.5 　 2,440.00
M14 1.00 12.00 22.0 83 12 4 J22012.0X1.0 　 3,195.00
M14 1.50 12.00 22.0 83 12 4 J22012.0X1.5 　 3,195.00
M16 1.00 14.00 26.0 83 14 5 J22014.0X1.0 　 3,930.00
M16 1.50 14.00 26.0 83 14 5 J22014.0X1.5 　 3,930.00
M20 2.00 16.00 30.0 92 16 5 J22016.0X2.0 　 4,715.00
M20 2.50 16.00 42.5 105 16 5 J22016.0X2.5 　 4,715.00
M24 3.00 19.00 50.0 125 20 5 J22019.0X3.0 　 5,660.00
M24 2.00 20.00 35.0 104 20 5 J22020.0X2.0 　 5,185.00
　
