＠：经销品牌>>DORMER>>DORMER丝锥>>EX41-英国多马DORMER丝锥

DORMER

EX41

G(BSP) 机用丝锥 螺旋槽 45°,提供HSS-E，直到新的可用库存
G TPI d1(mm) l1(mm) l2(mm) d2(mm) a(mm) l3(mm) z 底孔 订货号 　 RMB未税面价
1/8 28 9.728 90 13 7.0 5.5 8 3 8.8 EX411/8 　 368.00
1/4 19 13.157 100 15 11.0 9.0 12 3 11.8 EX411/4 　 610.00
3/8 19 16.662 100 15 12.0 9.0 12 4 15.25 EX413/8 　 625.00
1/2 14 20.955 125 18 16.0 12.0 15 4 19 EX411/2 　 955.00
5/8 14 22.911 125 18 18.0 14.5 17 4 21 EX415/8 　 1,720.00
3/4 14 26.441 140 20 20.0 16.0 19 4 24.5 EX413/4 　 1,825.00
7/8 14 30.201 150 20 22.0 18.0 21 4 28.25 EX417/8 　 2,130.00
1" 11 33.249 160 22 25.0 20.0 23 4 30.75 EX411 　 3,360.00
1.1/8 11 37.897 170 22 28.0 22.0 25 4 35 EX411.1/8 　 4,575.00
1.1/4 11 41.910 170 22 32.0 24.0 27 4 39.5 EX411.1/4 1) 5,365.00
1.1/2 11 47.803 190 23 36.0 29.0 32 4 45 EX411.1/2 1) 7,780.00
　
