＠：经销品牌>>DORMER>>DORMER丝锥>>EX21-英国多马DORMER丝锥

DORMER

EX21

UNC 机用丝锥 螺旋槽 45°,提供HSS-E，直到新的可用库存
UNC TPI d1(mm) l1(mm) l2(mm) d2(mm) a(mm) l3(mm) z 底孔 l4(mm) 订货号 　 RMB未税面价
4 40 2.845 56 6 3.5 2.7 6 3 2.35 18 EX214-40 　 304.00
5 40 3.175 56 6 3.5 2.7 6 3 2.65 18 EX215-40 　 304.00
6 32 3.505 56 7 4.0 3.0 6 3 2.85 20 EX216-32 　 304.00
8 32 4.166 63 7 4.5 3.4 8 3 3.5 21 EX218-32 　 308.00
10 24 4.826 70 8 6.0 4.9 8 3 3.9 25 EX2110-24 　 326.00
12 24 5.486 80 10 6.0 4.9 8 3 4.5 30 EX2112-24 　 328.00
1/4 20 6.350 80 10 7.0 5.5 8 3 5.1 30 EX211/4 　 328.00
5/16 18 7.938 90 12 8.0 6.2 9 3 6.6 35 EX215/16 　 420.00
3/8 16 9.525 100 15 10.0 8.0 11 3 8.0 39 EX213/8 　 496.00
7/16 14 11.112 100 15 8.0 6.2 9 3 9.4 - EX217/16 　 589.00
1/2 13 12.700 110 18 9.0 7.0 10 3 10.8 - EX211/2 　 589.00
5/8 11 15.875 110 20 12.0 9.0 12 4 13.5 - EX215/8 　 843.00
3/4 10 19.050 125 25 14.0 11.0 14 4 16.5 - EX213/4 　 1,215.00
7/8 9 22.225 140 25 18.0 14.5 17 4 19.5 - EX217/8 　 1,825.00
1" 8 25.400 160 30 18.0 14.5 17 4 22.25 - EX211 　 1,710.00
　
