＠：经销品牌>>DORMER>>DORMER丝锥>>EP006H-英国多马DORMER丝锥

DORMER

EP006H

M 机用螺尖 丝锥,提供HSS-E，直到新的可用库存
M P(mm) l1(mm) l2(mm) d2(mm) a(mm) l3(mm) z 底孔 l4(mm) 订货号 　 RMB未税面价
2 0.40 50 6 2.8 2.1 5 2 1.6 9 EP00M2 　 266.00
2.5 0.45 50 8 2.8 2.1 5 2 2.1 12.5 EP00M2.5 　 267.00
3 0.50 56 9 3.5 2.7 6 3 2.5 18 EP00M3 　 193.00
3 0.50 56 10 2.2 1.8 4 3 2.5 18 EP00M3DIN376 　 193.00
3.5 0.60 56 11 4.0 3.0 6 3 2.9 20 EP00M3.5 　 214.00
4 0.70 63 12 4.5 3.4 6 3 3.3 21 EP00M4 　 196.00
4 0.70 63 12 2.8 2.1 5 3 3.3 21 EP00M4DIN376 　 196.00
4.5 0.75 70 13 6.0 4.9 8 3 3.8 25 EP00M4.5 　 251.00
5 0.80 70 13 6.0 4.9 8 3 4.2 25 EP00M5 　 206.00
5 0.80 70 13 3.5 2.7 6 3 4.2 25 EP00M5DIN376 　 206.00
6 1.00 80 15 6.0 4.9 8 3 5 30 EP00M6 　 208.00
6 1.00 80 15 4.5 3.4 6 3 5 30 EP00M6DIN376 　 208.00
7 1.00 80 15 7.0 5.5 8 3 6 30 EP00M7 　 251.00
8 1.25 90 18 8.0 6.2 9 3 6.8 35 EP00M8 　 237.00
8 1.25 90 18 6.0 4.9 8 3 6.8 35 EP00M8DIN376 　 237.00
10 1.50 100 20 10.0 8.0 11 3 8.5 39 EP00M10 　 288.00
10 1.50 100 20 7.0 5.5 8 3 8.5 - EP00M10DIN376 　 288.00
12 1.75 110 23 9.0 7.0 10 3 10.3 - EP00M12 　 368.00
14 2.00 110 25 11.0 9.0 12 3 12 - EP00M14 　 516.00
16 2.00 110 25 12.0 9.0 12 3 14 - EP00M16 　 529.00
18 2.50 125 30 14.0 11.0 14 4 15.5 - EP00M18 　 763.00
20 2.50 140 30 16.0 12.0 15 4 17.5 - EP00M20 　 808.00
22 2.50 140 34 18.0 14.5 17 4 19.5 - EP00M22 　 1,140.00
24 3.00 160 38 18.0 14.5 17 4 21 - EP00M24 　 1,065.00
27 3.00 160 38 20.0 16.0 19 4 24 - EP00M27 　 1,530.00
30 3.50 180 45 22.0 18.0 21 4 26.5 - EP00M30 　 1,805.00
　
