DORMER

E550

Rc 机用丝锥 直槽
Rc TPI d1(mm) l1(mm) l2(mm) d2(mm) a(mm) l3(mm) z 底孔 订货号 　 RMB未税面价
1/8 28 9.728 59 15 8.0 6.3 9 3 8.4 E5501/8 　 311.00
1/8 28 9.728 59 15 8.0 6.3 9 3 8.4 E5501/8NO7 　 621.00
1/4 19 13.157 67 19 10.0 8.0 11 3 11.2 E5501/4 　 415.00
1/4 19 13.157 67 19 10.0 8.0 11 3 11.2 E5501/4NO7 　 831.00
3/8 19 16.662 75 21 12.5 10.0 13 3 14.75 E5503/8 　 617.00
3/8 19 16.662 75 21 12.5 10.0 13 3 14.75 E5503/8NO7 　 1,235.00
1/2 14 20.955 87 26 16.0 12.5 16 5 18.25 E5501/2 　 872.00
1/2 14 20.955 87 26 16.0 12.5 16 5 18.25 E5501/2NO7 　 1,745.00
3/4 14 26.441 96 28 20.0 16.0 20 5 23.75 E5503/4 　 1,300.00
3/4 14 26.441 96 28 20.0 16.0 20 5 23.75 E5503/4NO7 　 2,605.00
1" 11 33.249 109 33 25.0 20.0 24 5 30 E5501 　 2,180.00
1.1/4 11 41.910 119 36 31.5 25.0 28 5 38.5 E5501.1/4 　 3,865.00
1.1/2 11 47.803 125 37 35.5 28.0 31 7 44.5 E5501.1/2 　 4,900.00
2" 11 59.614 140 41 40.0 31.5 34 7 56 E5502 　 8,050.00
　
