经销品牌>>DORMER>>DORMER丝锥>>E414-英国多马DORMER丝锥

DORMER


E414

M 机用48°螺旋槽丝锥,蓝圈鲨鱼线,带背锥
M P(mm) l1(mm) l2(mm) d2(mm) a(mm) l3(mm) z 底孔 l4(mm) 订货号   RMB未税面价
3 0.50 56 6 3.5 2.7 6 3 2.5 18 E414M3   385.00
4 0.70 63 7 4.5 3.4 6 3 3.3 21 E414M4   391.00
5 0.80 70 8 6.0 4.9 8 3 4.2 25 E414M5   413.00
6 1.00 80 10 6.0 4.9 8 3 5.0 30 E414M6   415.00
8 1.25 90 13 8.0 6.2 9 3 6.8 35 E414M8   473.00
10 1.50 100 15 10.0 8.0 11 3 8.5 39 E414M10   576.00
12 1.75 110 18 9.0 7.0 10 3 10.3 - E414M12   737.00
14 2.00 110 20 11.0 9.0 12 3 12.0 - E414M14   1,030.00
16 2.00 110 20 12.0 9.0 12 4 14.0 - E414M16   1,060.00
20 2.50 140 25 16.0 12.0 15 4 17.5 - E414M20   1,615.00


DORMER
