＠：经销品牌>>DORMER>>DORMER丝锥>>E287-英国多马DORMER丝锥

DORMER

E287

UNC 机用挤压丝锥，油槽
UNC TPI d1(mm) l1(mm) l2(mm) d2(mm) a(mm) l3(mm) z 底孔 l4(mm) 订货号 　 RMB未税面价
4 40 2.845 56 9 3.5 2.7 6 4 2.6 18 E2874-40 　 498.00
6 32 3.505 56 11 4.0 3.0 6 4 3.2 20 E2876-32 　 498.00
8 32 4.166 63 12 4.5 3.4 6 5 3.8 21 E2878-32 　 504.00
10 24 4.826 70 13 6.0 4.9 8 5 4.4 25 E28710-24 　 533.00
1/4 20 6.350 80 15 7.0 5.5 8 5 5.8 30 E2871/4 　 536.00
5/16 18 7.938 90 18 8.0 6.2 9 5 7.3 35 E2875/16 　 688.00
3/8 16 9.525 100 20 10.0 8.0 11 5 8.8 39 E2873/8 　 811.00
7/16 14 11.112 100 20 8.0 6.2 9 5 10.3 - E2877/16 　 963.00
1/2 13 12.700 110 23 9.0 7.0 10 5 11.9 - E2871/2 　 963.00
　
