＠：经销品牌>>DORMER>>DORMER丝锥>>E031-英国多马DORMER丝锥

DORMER

E031

UNF 机用丝锥 螺尖,提供HSS-E，直到新的可用库存
UNF TPI d1(mm) l1(mm) l2(mm) d2(mm) a(mm) l3(mm) z 底孔 l4(mm) 订货号 　 RMB未税面价
8 36 4.166 53 9.5 4.5 3.55 6 3 3.50 17 E0318-36 　 308.00
10 32 4.826 58 11 5.0 4.00 7 3 4.10 20 E03110-32 　 326.00
1/4 28 6.350 66 13 6.3 5.00 8 3 5.50 26 E0311/4 　 328.00
5/16 24 7.938 72 16 8.0 6.30 9 3 6.90 29 E0315/16 　 420.00
3/8 24 9.525 80 18 10.0 8.00 11 3 8.50 32 E0313/8 　 496.00
7/16 20 11.112 85 19 8.0 6.30 9 3 9.90 - E0317/16 　 589.00
1/2 20 12.700 89 22 9.0 7.10 10 3 11.50 - E0311/2 　 589.00
9/16 18 14.288 95 24 11.2 9.00 12 3 12.90 - E0319/16 　 756.00
5/8 18 15.875 102 24 12.5 10.00 13 3 14.50 - E0315/8 　 843.00
3/4 16 19.050 112 29 14.0 11.20 14 4 17.50 - E0313/4 　 1,215.00
7/8 14 22.225 118 29 16.0 12.50 16 4 20.40 - E0317/8 　 1,825.00
1" 12 25.400 130 35 18.0 14.00 18 4 23.25 - E0311 　 1,710.00
　
