＠：经销品牌>>DORMER>>DORMER丝锥>>E030-英国多马DORMER丝锥

DORMER

E030

UNF 机用丝锥 螺尖
UNF TPI d1(mm) l1(mm) l2(mm) d2(mm) a(mm) l3(mm) z 底孔 l4(mm) 订货号 　 RMB未税面价
5/16 24 7.938 72 16 8.00 6.30 9 3 6.90 29 E0305/16 　 392.00
3/8 24 9.525 80 18 10.00 8.00 11 3 8.50 32 E0303/8 　 464.00
7/16 20 11.112 85 19 8.00 6.30 9 3 9.90 - E0307/16 　 550.00
1/2 20 12.700 89 22 9.00 7.10 10 3 11.50 - E0301/2 　 550.00
3/4 16 19.050 112 29 14.00 11.20 14 4 17.50 - E0303/4 　 1,130.00
7/8 14 22.225 118 29 16.00 12.50 16 4 20.40 - E0307/8 　 1,700.00
1" 12 25.400 130 35 18.00 14.00 18 4 23.25 - E0301 　 1,590.00
　
