＠：经销品牌>>DORMER>>DORMER铰刀>>B953-英国多马DORMER铰刀

DORMER

B953

45 度左螺旋圆锥销机用铰刀,扁尾符合 DIN 1809
nom d1(mm) d2(mm) l1(mm) l2(mm) z d3(mm) 订货号 　 RMB未税面价
1.0 0.8 1.46 60 33 2 1.4 B9531.0 　 584.00
1.5 1.4 2.14 70 37 2 2.1 B9531.5 　 432.00
2.0 1.9 2.86 86 48 3 3.15 B9532.0 　 444.00
2.5 2.4 3.36 86 48 3 3.15 B9532.5 　 482.00
3.0 2.9 4.06 100 58 3 4.0 B9533.0 　 441.00
4.0 3.9 5.26 112 68 3 5.0 B9534.0 　 459.00
5.0 4.9 6.36 122 73 3 6.3 B9535.0 　 499.00
6.0 5.9 8.00 160 105 3 8.0 B9536.0 　 541.00
6.5 6.4 8.78 188 119 3 8.5 B9536.5 　 649.00
8.0 7.9 10.80 207 145 3 10.0 B9538.0 　 832.00
10.0 9.9 13.40 245 175 3 12.5 B95310.0 　 1,150.00
12.0 11.8 16.00 290 210 3 16.0 B95312.0 　 1,660.00
　
