DORMER

B903

1:50手用锥销铰刀
nom d1(mm) d2(mm) l1(mm) l2(mm) z a(mm) d3(mm) 订货号 　 RMB未税面价
1.5 1.40 2.14 57 37 4 1.80 2.14 B9031.5 1) 727.00
2.0 1.90 2.86 68 48 4 2.24 2.86 B9032.0 1) 462.00
2.5 2.40 3.36 68 48 4 2.80 3.36 B9032.5 1) 516.00
3.0 2.90 4.06 80 58 4 3.15 4.00 B9033.0 1) 443.00
4.0 3.90 5.26 93 68 4 4.00 5.00 B9034.0 1) 494.00
5.0 4.90 6.36 100 73 4 5.00 6.30 B9035.0 1) 535.00
6.0 5.90 8.00 135 105 6 6.30 7.90 B9036.0 2) 621.00
8.0 7.90 10.80 180 145 6 8.00 10.50 B9038.0 2) 786.00
10.0 9.90 13.40 215 175 6 10.00 13.30 B90310.0 2) 1,110.00
12.0 11.80 16.00 255 210 8 11.20 16.00 B90312.0 2) 1,280.00
13.0 12.86 16.74 255 210 8 12.50 16.74 B90313.0 2) 1,495.00
14.0 13.86 17.74 255 210 8 12.50 17.74 B90314.0 2) 2,325.00
16.0 15.80 20.40 280 230 8 14.00 20.40 B90316.0 2) 2,595.00
20.0 19.80 24.80 310 250 8 18.00 24.80 B90320.0 2) 3,835.00
1) 公差极限 + 0.0750 2) 公差极限 + 0.125
　
