＠：经销品牌>>DORMER>>DORMER铰刀>>B481-英国多马DORMER铰刀

DORMER

B481

NC-用于高精度夹头以丝为单位的铰刀,极不等距
d1(mm) l1(mm) l2(mm) l3(mm) z d2(mm) 订货号 　 RMB未税面价
0.98 49.5 6 21.5 3 4 B4810.98 　 839.00
0.99 49.5 6 21.5 3 4 B4810.99 　 839.00
1.00 49.5 6 21.5 3 4 B4811.00 　 733.00
1.01 49.5 6 21.5 3 4 B4811.01 　 839.00
1.02 49.5 6 21.5 3 4 B4811.02 　 839.00
1.03 49.5 9 21.5 3 4 B4811.03 　 839.00
1.48 49 9 21 3 4 B4811.48 　 850.00
1.49 49 9 21 3 4 B4811.49 　 850.00
1.50 49 9 21 3 4 B4811.50 　 743.00
1.51 49 9 21 3 4 B4811.51 　 850.00
1.52 49 9 21 3 4 B4811.52 　 850.00
1.53 49 9 21 3 4 B4811.53 　 850.00
1.98 49 12 21 4 4 B4811.98 　 850.00
1.99 49 12 21 4 4 B4811.99 　 850.00
2.00 49 12 21 4 4 B4812.00 　 743.00
2.01 49 12 21 4 4 B4812.01 　 850.00
2.02 49 12 21 4 4 B4812.02 　 850.00
2.03 49 12 21 4 4 B4812.03 　 850.00
2.48 59 16 31 4 4 B4812.48 　 850.00
2.49 59 16 31 4 4 B4812.49 　 850.00
2.50 59 16 31 4 4 B4812.50 　 743.00
2.51 59 16 31 4 4 B4812.51 　 850.00
2.52 59 16 31 4 4 B4812.52 　 850.00
2.53 59 16 31 4 4 B4812.53 　 850.00
2.97 62.5 17 35 6 4 B4812.97 　 882.00
2.98 62.5 17 35 6 4 B4812.98 　 882.00
2.99 62.5 17 35 6 4 B4812.99 　 882.00
3.00 62.5 17 35 6 4 B4813.00 　 775.00
3.01 62.5 17 35 6 4 B4813.01 　 882.00
3.02 62.5 17 35 6 4 B4813.02 　 882.00
3.03 62.5 17 35 6 4 B4813.03 　 882.00
3.97 75 19 47 6 4 B4813.97 　 1,040.00
3.98 75 19 47 6 4 B4813.98 　 1,040.00
3.99 75 19 47 6 4 B4813.99 　 1,040.00
4.00 75 19 47 6 4 B4814.00 　 924.00
4.01 75 19 47 6 4 B4814.01 　 1,040.00
4.02 75 19 47 6 4 B4814.02 　 1,040.00
4.03 75 19 47 6 4 B4814.03 　 1,040.00
4.97 86 23 50 6 6 B4814.97 　 1,135.00
4.98 86 23 50 6 6 B4814.98 　 1,135.00
4.99 86 23 50 6 6 B4814.99 　 1,135.00
5.00 86 23 50 6 6 B4815.00 　 1,030.00
5.01 86 23 50 6 6 B4815.01 　 1,135.00
5.02 86 23 50 6 6 B4815.02 　 1,135.00
5.03 86 23 50 6 6 B4815.03 　 1,135.00
5.97 93 26 57 6 6 B4815.97 　 1,230.00
5.98 93 26 57 6 6 B4815.98 　 1,230.00
5.99 93 26 57 6 6 B4815.99 　 1,230.00
6.00 93 26 57 6 6 B4816.00 　 1,125.00
6.01 93 26 57 6 6 B4816.01 　 1,230.00
6.02 93 26 57 6 6 B4816.02 　 1,230.00
6.03 93 26 57 6 6 B4816.03 　 1,230.00
7.97 117 33 81 6 8 B4817.97 　 1,550.00
7.98 117 33 81 6 8 B4817.98 　 1,550.00
7.99 117 33 81 6 8 B4817.99 　 1,550.00
8.00 117 33 81 6 8 B4818.00 　 1,435.00
8.01 117 33 81 6 8 B4818.01 　 1,550.00
8.02 117 33 81 6 8 B4818.02 　 1,550.00
8.03 117 33 81 6 8 B4818.03 　 1,550.00
8.04 117 33 81 6 8 B4818.04 　 1,550.00
9.97 133 38 93 6 10 B4819.97 　 1,805.00
9.98 133 38 93 6 10 B4819.98 　 1,805.00
9.99 133 38 93 6 10 B4819.99 　 1,805.00
10.00 133 38 93 6 10 B48110.00 　 1,690.00
10.01 133 38 93 6 10 B48110.01 　 1,805.00
10.02 133 38 93 6 10 B48110.02 　 1,805.00
10.03 133 38 93 6 10 B48110.03 　 1,805.00
10.04 133 38 93 6 10 B48110.04 　 1,805.00
10.05 133 38 93 6 10 B48110.05 　 1,805.00
11.97 151 44 106 6 12 B48111.97 　 2,165.00
11.98 151 44 106 6 12 B48111.98 　 2,165.00
11.99 151 44 106 6 12 B48111.99 　 2,165.00
12.00 151 44 106 6 12 B48112.00 　 2,050.00
12.01 151 44 106 6 12 B48112.01 　 2,165.00
12.02 151 44 106 6 12 B48112.02 　 2,165.00
12.03 151 44 106 6 12 B48112.03 　 2,165.00
12.04 151 44 106 6 12 B48112.04 　 2,165.00
12.05 151 44 106 6 12 B48112.05 　 2,165.00
　
