＠：经销品牌>>DORMER>>DORMER铰刀>>B334-英国多马DORMER铰刀

DORMER

B334

手用可调铰刀
Nr. d1min-max(mm) l1(mm) l2(mm) l3(mm) z a(mm) 订货号 　 RMB未税面价
000 6.4 - 7.2 110 32 7 4 3.0 B334000 　 1,490.00
00 7.2 - 8.0 110 32 7 4 3.4 B33400 　 1,490.00
0 8.0 - 9.0 115 34 9 5 3.8 B3340 　 1,490.00
1 9.0 - 10.0 115 34 9 5 4.3 B3341 　 1,570.00
2 10.0 - 11.0 115 34 9 5 4.9 B3342 　 1,570.00
3 11.0 - 12.0 125 35 9 5 4.9 B3343 　 1,570.00
4 12.0 - 13.5 135 41 9 5 6.2 B3344 　 1,775.00
5 13.5 - 15.5 146 50 12 5 7.0 B3345 　 1,960.00
6 15.5 - 18.0 166 60 12 5 8.0 B3346 　 2,015.00
7 18.0 - 21.0 178 65 15 5 9.0 B3347 　 2,200.00
8 21.0 - 24.0 195 76 15 5 11.0 B3348 　 2,645.00
9 24.0 - 27.5 218 82 18 5 12.0 B3349 　 2,805.00
10 27.5 - 31.5 245 86 18 5 14.5 B33410 　 3,425.00
11 31.5 - 37.0 280 98 18 6 18.0 B33411 　 4,780.00
12 37.0 - 45.0 325 108 20 6 20.0 B33412 　 6,200.00
13 45.0 - 55.0 370 118 20 6 26.0 B33413 　 8,390.00
14 55.0 - 67.0 400 125 20 6 32.0 B33414 　 10,725.00
15 67.0 - 80.0 435 140 23 8 39.0 B33415 　 16,510.00
16 80.0 - 95.0 475 155 23 8 49.0 B33416 　 22,990
　
