DORMER

B157

45 度左螺旋机用铰刀
d1(mm) l1(mm) l2(mm) l3(mm) l4(mm) z d2(mm) 订货号 　 RMB未税面价
2.0 49 11 3.5 24 3 2.0 B1572.0 　 379.00
3.0 61 15 4.0 32 3 3.0 B1573.0 　 317.00
4.0 75 19 4.0 43 3 4.0 B1574.0 　 351.00
5.0 86 23 4.5 52 3 5.0 B1575.0 　 358.00
6.0 93 26 6.0 57 3 5.6 B1576.0 　 485.00
7.0 109 31 7.0 69 3 7.1 B1577.0 　 460.00
8.0 117 33 9.0 75 3 8.0 B1578.0 　 467.00
9.0 125 36 9.5 81 3 9.0 B1579.0 　 558.00
10.0 133 38 10.0 87 3 10.0 B15710.0 　 542.00
11.0 142 41 10.5 96 3 10.0 B15711.0 　 740.00
12.0 151 44 11.0 105 3 10.0 B15712.0 　 757.00
13.0 151 44 11.5 105 3 10.0 B15713.0 　 841.00
14.0 160 47 12.0 110 3 12.5 B15714.0 　 889.00
15.0 162 50 12.5 112 3 12.5 B15715.0 　 910.00
16.0 170 52 13.0 120 3 12.5 B15716.0 　 965.00
17.0 175 54 13.5 123 3 14.0 B15717.0 　 1,160.00
18.0 182 56 14.0 130 3 14.0 B15718.0 　 1,235.00
19.0 189 58 14.5 131 3 16.0 B15719.0 　 1,455.00
20.0 195 60 15.0 137 3 16.0 B15720.0 　 1,385.00
　
