＠：经销品牌>>DORMER>>DORMER铰刀>>B121-英国多马DORMER铰刀

DORMER

B121

莫氏锥柄扩孔铰刀,起始锥度 (l3) 为 1:10
d1(mm) l1(mm) l2(mm) l3(mm) z MK 订货号 　 RMB未税面价
10.0 171 95 30 4 1 B12110.0 　 987.00
11.0 176 100 33 4 1 B12111.0 　 987.00
12.0 199 105 39 4 2 B12112.0 　 1,075.00
13.0 199 105 39 4 2 B12113.0 　 1,075.00
14.0 209 115 42 4 2 B12114.0 　 1,095.00
15.0 219 125 45 4 2 B12115.0 　 1,115.00
16.0 229 135 48 4 2 B12116.0 　 1,135.00
17.0 251 135 51 4 3 B12117.0 　 1,325.00
18.0 261 145 58 4 3 B12118.0 　 1,430.00
19.0 261 145 58 4 3 B12119.0 　 1,515.00
20.0 271 155 62 4 3 B12120.0 　 1,650.00
21.0 271 155 62 4 3 B12121.0 　 1,765.00
22.0 281 165 66 4 3 B12122.0 　 1,965.00
23.0 281 165 66 4 3 B12123.0 　 2,135.00
24.0 296 180 72 4 3 B12124.0 　 2,270.00
25.0 296 180 72 4 3 B12125.0 　 2,365.00
26.0 296 180 72 4 3 B12126.0 　 2,520.00
30.0 311 195 78 5 3 B12130.0 　 3,115.00
　

DORMER
