经销品牌>>DORMER>>DORMER铣刀>>S767-英国多马DORMER铣刀

DORMER


S767

立铣刀-刀尖带圆角的立铣刀
d1(mm) r±0.01(mm) d2(mm) l2(mm) l1(mm) z 订货号   RMB未税面价
4.00 0.30 6 11 57 4 S7674.0XR0.3   562.00
4.00 0.50 6 11 57 4 S7674.0XR0.5   562.00
5.00 0.30 6 13 57 4 S7675.0XR0.3   573.00
5.00 0.50 6 13 57 4 S7675.0XR0.5   573.00
6.00 0.30 6 13 57 4 S7676.0XR0.3   573.00
6.00 0.50 6 13 57 4 S7676.0XR0.5   573.00
6.00 1.00 6 13 57 4 S7676.0XR1.0   573.00
8.00 0.30 8 20 64 4 S7678.0XR0.3   803.00
8.00 0.50 8 20 64 4 S7678.0XR0.5   803.00
8.00 1.00 8 20 64 4 S7678.0XR1.0   803.00
10.00 0.30 10 22 72 4 S76710.0XR0.3   1,060.00
10.00 0.50 10 22 72 4 S76710.0XR0.5   1,060.00
10.00 1.00 10 22 72 4 S76710.0XR1.0   1,060.00
12.00 0.30 12 26 83 4 S76712.0XR0.3   1,460.00
12.00 0.50 12 26 83 4 S76712.0XR0.5   1,460.00
12.00 1.00 12 26 83 4 S76712.0XR1.0   1,460.00
12.00 2.00 12 26 83 4 S76712.0XR2.0   1,460.00
16.00 0.30 16 32 92 4 S76716.0XR0.3   2,410.00
16.00 0.50 16 32 92 4 S76716.0XR0.5   2,410.00
16.00 1.00 16 32 92 4 S76716.0XR1.0   2,410.00
16.00 2.00 16 32 92 4 S76716.0XR2.0   2,410.00
20.00 0.30 20 38 104 4 S76720.0XR0.3   3,725.00
20.00 0.50 20 38 104 4 S76720.0XR0.5   3,725.00
20.00 1.00 20 38 104 4 S76720.0XR1.0   3,725.00
20.00 2.00 20 38 104 4 S76720.0XR2.0   3,725.00
