＠：经销品牌>>DORMER>>DORMER铣刀>>C837-英国多马DORMER铣刀

DORMER

C837

铣刀
B(mm) d1(Inch) d1(mm) d3(mm) l2(mm) l1(mm) d2Ř0,-0.025 d2Ř0,-0.025 z 订货号 　 RMB未税面价
45° 3.0 　 13.00 4.75 16.5 63.5 　 12.00 6 C83713.0 　 576.00
45° 4.0 5/8 15.88 6.35 17.5 66.5 1/2 12.70 6 C8375/8 1) 743.00
45° 4.0 　 16.00 6.35 17.5 66.5 　 12.00 6 C83716.0 　 676.00
45° 5.5 　 19.00 6.35 16.0 66.5 　 12.00 6 C83719.0 　 754.00
45° 5.5 3/4 19.05 6.35 16.0 66.5 1/2 12.70 6 C8373/4 1) 744.00
45° 6.5 　 22.00 7.15 16.0 68.5 　 12.00 6 C83722.0 　 854.00
45° 6.5 7/8 22.23 7.15 16.0 68.5 1/2 12.70 6 C8377/8 1) 912.00
45° 7.5 　 25.00 7.95 16.5 70.0 　 12.00 6 C83725.0 　 1,070.00
45° 8.0 1" 25.40 7.95 16.0 70.0 1/2 12.70 6 C8371 　 903.00
45° 8.5 　 28.00 9.55 17.0 71.5 　 16.00 6 C83728.0 　 1,210.00
45° 10.5 　 38.00 12.70 16.0 78.5 　 25.00 8 C83738.0 　 2,140.00
　
