DORMER

C835

铣刀
B(mm) d1(Inch) d1(mm) d3(mm) l2(mm) l1(mm) d2Ř0,-0.025 d2Ř0,-0.025 z 订货号 　 RMB未税面价
60° 4.0 1/2 12.70 7.15 16.5 63.5 1/2 12.70 6 C8351/2 1) 514.00
60° 4.0 　 13.00 7.15 16.5 63.5 　 12.00 6 C83513.0 　 548.00
60° 5.5 5/8 15.88 7.55 18.0 66.5 1/2 12.70 6 C8355/8 1) 743.00
60° 5.5 　 16.00 7.55 18.0 66.5 　 12.00 6 C83516.0 　 671.00
60° 7.0 　 19.00 8.35 17.5 67.5 　 12.00 6 C83519.0 　 754.00
60° 7.0 3/4 19.05 8.35 17.5 67.5 1/2 12.70 6 C8353/4 1) 683.00
60° 9.5 　 22.00 8.75 15.0 67.5 　 12.00 6 C83522.0 　 854.00
60° 9.5 7/8 22.23 8.75 15.0 67.5 1/2 12.70 6 C8357/8 1) 912.00
60° 12.0 　 25.00 8.75 15.0 70.0 　 12.00 6 C83525.0 　 1,070.00
60° 12.0 1" 25.40 8.75 15.0 70.0 1/2 12.70 6 C8351 1) 903.00
60° 12.5 　 28.00 11.10 15.5 73.0 　 16.00 6 C83528.0 　 1,210.00
60° 12.5 1.1/8 28.58 11.10 15.5 73.0 5/8 15.88 6 C8351.1/8 1) 1,210.00
60° 13.5 　 32.00 12.70 16.0 74.5 　 16.00 8 C83532.0 　 1,425.00
60° 13.5 1.1/4 31.75 12.70 16.0 74.5 5/8 15.88 8 C8351.1/4 1) 1,425.00
60° 14.5 1.3/8 34.93 12.70 16.0 82.5 1" 25.40 8 C8351.3/8 1) 2,140.00
60° 14.5 　 35.00 12.70 16.0 82.5 　 25.00 8 C83535.0 　 1,955.00
60° 16.0 　 38.00 17.45 16.0 84.0 　 25.00 8 C83538.0 　 2,140.00
60° 16.0 1.1/2 38.10 17.45 16.0 84.0 1" 25.40 8 C8351.1/2 1) 2,335.00
　
