C123,英国多马DORMER铣刀C123//上海简文

C123

铣刀

d₁(Inch)	d₁_(mm)	d₂_(mm)	l₂_(mm)	l₁_(mm)	z	l₃_(mm)	d_3(mm)	订货号		RMB未税面价
1/16	1.59	6	7	51	2	-	-	C1231/16	²⁾	235.00
	2.00	6	7	51	2	-	-	C1232.0		235.00
	2.50	6	8	52	2	-	-	C1232.5		241.00
	3.00	6	8	52	2	-	-	C1233.0		223.00
1/8	3.18	6	10	54	2	-	-	C1231/8	²⁾	228.00
	3.50	6	10	54	2	-	-	C1233.5		228.00
5/32	3.97	6	11	55	2	-	-	C1235/32	²⁾	228.00
	4.00	6	11	55	2	-	-	C1234.0		223.00
	4.50	6	11	55	2	-	-	C1234.5		243.00
3/16	4.76	6	13	57	2	-	-	C1233/16	²⁾	243.00
	5.00	6	13	57	2	-	-	C1235.0		221.00
	5.50	6	13	57	2	-	-	C1235.5		268.00
	6.00	6	13	57	2	-	-	C1236.0		222.00
1/4	6.35	10	16	66	2	-	-	C1231/4	²⁾	298.00
	6.50	10	16	66	2	-	-	C1236.5		298.00
	7.00	10	16	66	2	-	-	C1237.0		314.00
	7.50	10	16	66	2	-	-	C1237.5		298.00
5/16	7.94	10	19	69	2	-	-	C1235/16	²⁾	298.00
	8.00	10	19	69	2	-	-	C1238.0		281.00
	8.50	10	19	69	2	-	-	C1238.5		325.00
	9.00	10	19	69	2	-	-	C1239.0		342.00
	9.50	10	19	69	2	-	-	C1239.5		325.00
3/8	9.52	10	22	72	2	31.5	9.5	C1233/8	²⁾	325.00
	10.00	10	22	72	2	31.5	9.5	C12310.0		308.00
	11.00	12	22	79	2	-	-	C12311.0		404.00
	12.00	12	26	83	2	37.5	11.5	C12312.0		364.00
1/2	12.70	12	26	83	2	37.5	11.5	C1231/2	²⁾	486.00
	13.00	12	26	83	2	37.5	11.5	C12313.0		486.00
	14.00	12	26	83	2	37.5	11.5	C12314.0		456.00
9/16	14.29	12	26	83	2	37.5	11.5	C1239/16	²⁾	541.00
	15.00	12	26	83	2	37.5	11.5	C12315.0		541.00
5/8	15.88	16	32	92	2	43.5	15.5	C1235/8	²⁾	546.00
	16.00	16	32	92	2	43.5	15.5	C12316.0		546.00
	18.00	16	32	92	2	43.5	15.5	C12318.0		620.00
3/4	19.05	20	38	104	2	53.5	18.5	C1233/4	³⁾	723.00
	20.00	20	38	104	2	53.5	19.5	C12320.0		723.00
	22.00	20	38	104	2	53.5	19.5	C12322.0		937.00
	25.00	25	45	121	2	64.5	24.5	C12325.0		1,215.00
1''	25.40	25	45	121	2	64.5	24.5	C1231		1,520.00
	30.00	25	45	121	2	64.5	24.5	C12330.0		1,520.00
	32.00	32	53	133	2	72.5	31.5	C12332.0		1,775.00
