经销品牌>>DORMER>>DORMER铣刀>>C110-英国多马DORMER铣刀

DORMER


C110

铣刀-钻铣刀
d1(Inch) d1(mm) d2(mm) l2(mm) l1(mm) z l3(mm) d3(mm) 订货号   RMB未税面价
  1.00 6 2.5 47 2 - - C1101.0   277.00
  1.50 6 3 47 2 - - C1101.5   251.00
1/16 1.59 6 3 47 2 - - C1101/16   214.00
  1.80 6 4 48 2 - - C1101.8   214.00
  2.00 6 4 48 2 - - C1102.0   181.00
3/32 2.38 6 5 49 2 - - C1103/32   186.00
  2.50 6 5 49 2 - - C1102.5   186.00
  2.80 6 5 49 2 - - C1102.8   155.00
  3.00 6 5 49 2 - - C1103.0   171.00
1/8 3.18 6 6 50 2 - - C1101/8   175.00
  3.50 6 6 50 2 - - C1103.5   175.00
  3.80 6 7 51 2 - - C1103.8   161.00
  4.00 6 7 51 2 - - C1104.0   171.00
  4.50 6 7 51 2 - - C1104.5   187.00
3/16 4.76 6 8 52 2 - - C1103/16   186.00
  4.80 6 8 52 2 - - C1104.8 1)2) 186.00
  5.00 6 8 52 2 - - C1105.0   169.00
  5.50 6 8 52 2 - - C1105.5   206.00
  5.75 6 8 52 2 - - C1105.75 1)2) 215.00
  6.00 6 8 52 2 - - C1106.0   171.00
1/4 6.35 10 10 60 2 - - C1101/4   278.00
  6.50 10 10 60 2 - - C1106.5   278.00
  6.75 10 10 60 2 - - C1106.75   277.00
  7.00 10 10 60 2 - - C1107.0   265.00
  7.50 10 10 60 2 - - C1107.5   279.00
  7.75 10 11 61 2 - - C1107.75 1)2) 287.00
5/16 7.94 10 11 61 2 - - C1105/16   287.00
  8.00 10 11 61 2 - - C1108.0   238.00
  8.50 10 11 61 2 - - C1108.5   304.00
  9.00 10 11 61 2 - - C1109.0   289.00
  9.50 10 11 61 2 - - C1109.5   315.00
3/8 9.52 10 13 63 2 22.5 9.5 C1103/8   323.00
  10.00 10 13 63 2 22.5 9.5 C11010.0   261.00
13/32 10.32 12 13 70 2 - - C11013/32   373.00
  10.50 12 13 70 2 - - C11010.5   373.00
  11.00 12 13 70 2 - - C11011.0   342.00
7/16 11.11 12 13 70 2 - - C1107/16   351.00
  11.50 12 13 70 2 - - C11011.5   351.00
  12.00 12 16 73 2 27.5 11.5 C11012.0   308.00
  12.50 12 16 73 2 27.5 11.5 C11012.5   422.00
1/2 12.70 12 16 73 2 27.5 11.5 C1101/2   456.00
  13.00 12 16 73 2 27.5 11.5 C11013.0   411.00
17/32 13.49 12 16 73 2 27.5 11.5 C11017/32   422.00
  13.70 12 16 73 2 27.5 11.5 C11013.7 1)2) 422.00
  14.00 12 16 73 2 27.5 11.5 C11014.0   385.00
9/16 14.29 12 16 73 2 27.5 11.5 C1109/16   458.00
  15.00 12 16 73 2 27.5 11.5 C11015.0   458.00
  15.70 16 19 79 2 30.5 15.5 C11015.7 1)2) 475.00
5/8 15.88 16 19 79 2 30.5 15.5 C1105/8   475.00
  16.00 16 19 79 2 30.5 15.5 C11016.0   461.00
  17.00 16 19 79 2 30.5 15.5 C11017.0   592.00
11/16 17.46 16 19 79 2 30.5 15.5 C11011/16   612.00
  18.00 16 19 79 2 30.5 15.5 C11018.0   524.00
  19.00 16 19 79 2 30.5 15.5 C11019.0   682.00
3/4 19.05 20 22 88 2 37.5 18.5 C1103/4   738.00
  19.70 20 22 88 2 37.5 19.5 C11019.7   738.00
  20.00 20 22 88 2 37.5 19.5 C11020.0   612.00
  21.70 20 22 88 2 37.5 19.5 C11021.7   912.00
  22.00 20 22 88 2 37.5 19.5 C11022.0   794.00
7/8 22.22 20 22 88 2 37.5 19.5 C1107/8   1,060.00
  24.00 25 26 102 2 45.5 23.5 C11024.0   1,060.00
  24.70 25 26 102 2 45.5 24.5 C11024.7   1,195.00
  25.00 25 26 102 2 45.5 24.5 C11025.0   1,030.00
1'' 25.40 25 26 102 2 45.5 24.5 C1101   1,215.00
  26.00 25 26 102 2 45.5 24.5 C11026.0   1,215.00
  28.00 25 26 102 2 45.5 24.5 C11028.0   1,245.00
1.1/8 28.58 25 26 102 2 45.5 24.5 C1101.1/8   1,285.00
  30.00 25 26 102 2 45.5 24.5 C11030.0   1,285.00
  32.00 32 32 112 2 51.5 31.5 C11032.0   1,500.00
  35.00 32 32 112 2 51.5 31.5 C11035.0 1)3) 1,600.00
  36.00 32 32 112 2 51.5 31.5 C11036.0 1)3) 1,600.00
  40.00 40 38 130 2 59.5 39.0 C11040.0 1)3) 2,225.00
  45.00 40 38 130 2 59.5 38.0 C11045.0 1)3) 2,730.00
