＠：经销品牌>>DORMER>>DORMER钻头>>A553-英国多马DORMER钻头

DORMER

A553

ADX 钻头,内冷
d1(mm) d1(inch) l2(mm) l1(mm) l3(mm) d2(mm) 订货号 　 RMB未税面价
5.00 0.1969 36 79 36 6 A5535.0 　 1,415.00
5.20 0.2047 38 79 36 6 A5535.2 　 1,415.00
5.50 0.2165 40 79 36 6 A5535.5 　 1,415.00
6.00 0.2362 43 79 36 6 A5536.0 　 1,415.00
6.30 0.2480 46 87 36 8 A5536.3 　 1,490.00
6.50 0.2559 47 87 36 8 A5536.5 　 1,490.00
6.80 0.2677 48 87 36 8 A5536.8 　 1,490.00
6.90 0.2717 48 87 36 8 A5536.9 　 1,490.00
7.00 0.2756 48 87 36 8 A5537.0 　 1,490.00
7.40 0.2913 54 94 36 8 A5537.4 　 1,490.00
7.50 0.2953 54 94 36 8 A5537.5 　 1,490.00
8.00 0.3150 58 94 36 8 A5538.0 　 1,575.00
8.50 0.3346 75 130 40 10 A5538.5 　 1,750.00
8.70 0.3425 75 130 40 10 A5538.7 　 1,750.00
9.00 0.3543 75 130 40 10 A5539.0 　 1,750.00
9.50 0.3740 75 130 40 10 A5539.5 　 1,750.00
10.00 0.3937 75 130 40 10 A55310.0 　 1,750.00
10.20 0.4016 87 150 45 12 A55310.2 　 1,940.00
10.30 0.4055 87 150 45 12 A55310.3 　 1,940.00
10.50 0.4134 87 150 45 12 A55310.5 　 1,940.00
11.00 0.4331 94 150 45 12 A55311.0 　 1,940.00
11.30 0.4449 94 150 45 12 A55311.3 　 1,940.00
11.50 0.4528 94 150 45 12 A55311.5 　 1,940.00
12.00 0.4724 94 150 45 12 A55312.0 　 1,940.00
12.50 0.4921 101 160 45 14 A55312.5 　 2,435.00
13.00 0.5118 101 160 45 14 A55313.0 　 2,435.00
13.50 0.5315 101 160 45 14 A55313.5 　 2,435.00
14.00 0.5512 101 160 45 14 A55314.0 　 2,435.00
14.25 0.5610 108 170 48 16 A55314.25 　 3,310.00
14.50 0.5709 108 170 48 16 A55314.5 　 3,310.00
15.00 0.5906 108 170 48 16 A55315.0 　 3,310.00
15.25 0.6004 108 170 48 16 A55315.25 　 3,310.00
15.50 0.6102 108 170 48 16 A55315.5 　 3,310.00
16.00 0.6299 108 170 48 16 A55316.0 　 3,310.00
16.50 0.6496 125 190 48 18 A55316.5 　 4,145.00
17.00 0.6693 125 190 48 18 A55317.0 　 4,145.00
17.50 0.6890 130 190 48 18 A55317.5 　 4,145.00
17.75 0.6988 130 190 48 18 A55317.75 　 4,145.00
18.00 0.7087 130 190 48 18 A55318.0 　 4,145.00
19.00 0.7480 135 200 50 20 A55319.0 　 4,995.00
19.25 0.7579 140 200 50 20 A55319.25 　 4,995.00
20.00 0.7874 140 200 50 20 A55320.0 　 4,995.00
　
