A350,英国多马DORMER高速钢钻头A350//上海简文

d1(mm)	d1(inch)	l2(mm)	l1(mm)	MK	订货号	RMB未税面价
5.00	0.1969	74	155	1	A3505.0	327.00
5.50	0.2165	80	161	1	A3505.5	351.00
6.00	0.2362	80	161	1	A3506.0	310.00
6.70	0.2638	86	167	1	A3506.7	578.00
6.80	0.2677	93	174	1	A3506.8	503.00
7.00	0.2756	93	174	1	A3507.0	340.00
7.50	0.2953	93	174	1	A3507.5	380.00
8.00	0.3150	100	181	1	A3508.0	332.00
8.40	0.3307	100	181	1	A3508.4	583.00
8.50	0.3346	100	181	1	A3508.5	359.00
8.75	0.3445	107	188	1	A3508.75	459.00
9.00	0.3543	107	188	1	A3509.0	378.00
9.50	0.3740	107	188	1	A3509.5	425.00
9.80	0.3858	116	197	1	A3509.8	668.00
10.00	0.3937	116	197	1	A35010.0	387.00
10.20	0.4016	116	197	1	A35010.2	539.00
10.50	0.4134	116	197	1	A35010.5	434.00
10.70	0.4213	125	206	1	A35010.7	671.00
11.00	0.4331	125	206	1	A35011.0	431.00
11.50	0.4528	125	206	1	A35011.5	463.00
11.75	0.4626	125	206	1	A35011.75	491.00
11.80	0.4646	125	206	1	A35011.8	657.00
12.00	0.4724	134	215	1	A35012.0	446.00
12.50	0.4921	134	215	1	A35012.5	495.00
13.00	0.5118	134	215	1	A35013.0	491.00
13.50	0.5315	142	223	1	A35013.5	567.00
14.00	0.5512	142	223	1	A35014.0	540.00
14.25	0.5610	147	245	2	A35014.25	739.00
14.50	0.5709	147	245	2	A35014.5	618.00
14.75	0.5807	147	245	2	A35014.75	742.00
15.00	0.5906	147	245	2	A35015.0	606.00
15.25	0.6004	153	251	2	A35015.25	820.00
15.50	0.6102	153	251	2	A35015.5	685.00
15.75	0.6201	153	251	2	A35015.75	756.00
16.00	0.6299	153	251	2	A35016.0	650.00
16.25	0.6398	159	257	2	A35016.25	811.00
16.50	0.6496	159	257	2	A35016.5	746.00
16.75	0.6594	159	257	2	A35016.75	878.00
17.00	0.6693	159	257	2	A35017.0	723.00
17.25	0.6791	165	263	2	A35017.25	964.00
17.50	0.6890	165	263	2	A35017.5	872.00
18.00	0.7087	165	263	2	A35018.0	846.00
18.50	0.7283	171	269	2	A35018.5	996.00
19.00	0.7480	171	269	2	A35019.0	971.00
19.50	0.7677	177	275	2	A35019.5	1,160.00
19.75	0.7776	177	275	2	A35019.75	1,035.00
20.00	0.7874	177	275	2	A35020.0	977.00
20.25	0.7972	184	282	2	A35020.25	1,165.00
20.50	0.8071	184	282	2	A35020.5	1,030.00
21.00	0.8268	184	282	2	A35021.0	999.00
21.50	0.8465	191	289	2	A35021.5	1,185.00
22.00	0.8661	191	289	2	A35022.0	1,150.00
22.50	0.8858	198	296	2	A35022.5	1,260.00
23.00	0.9055	198	296	2	A35023.0	1,240.00
23.50	0.9252	198	319	3	A35023.5	1,380.00
24.00	0.9449	206	327	3	A35024.0	1,365.00
24.50	0.9646	206	327	3	A35024.5	1,510.00
25.00	0.9843	206	327	3	A35025.0	1,410.00
25.50	1.0039	214	335	3	A35025.5	1,720.00
26.00	1.0236	214	335	3	A35026.0	1,685.00
26.50	1.0433	214	335	3	A35026.5	1,760.00
27.00	1.0630	222	343	3	A35027.0	1,760.00
27.50	1.0827	222	343	3	A35027.5	1,850.00
28.00	1.1024	222	343	3	A35028.0	1,850.00
29.00	1.1417	230	351	3	A35029.0	2,015.00
30.00	1.1811	230	351	3	A35030.0	2,115.00
30.50	1.2008	239	360	3	A35030.5	2,670.00
31.00	1.2205	239	360	3	A35031.0	2,415.00
31.50	1.2402	239	360	3	A35031.5	3,110.00
32.00	1.2598	248	397	4	A35032.0	2,650.00
33.00	1.2992	248	397	4	A35033.0	2,870.00
34.00	1.3386	257	406	4	A35034.0	3,150.00
35.00	1.3780	257	406	4	A35035.0	3,250.00
36.00	1.4173	267	416	4	A35036.0	3,590.00
37.00	1.4567	267	416	4	A35037.0	3,855.00
38.00	1.4961	277	426	4	A35038.0	4,115.00
39.00	1.5354	277	426	4	A35039.0	4,355.00
40.00	1.5748	277	426	4	A35040.0	4,465.00
41.00	1.6142	287	436	4	A35041.0	5,090.00
42.00	1.6535	287	436	4	A35042.0	5,355.00
43.00	1.6929	298	447	4	A35043.0	5,710.00
44.00	1.7323	298	447	4	A35044.0	5,930.00
45.00	1.7717	298	447	4	A35045.0	6,160.00
46.00	1.8110	310	459	4	A35046.0	6,485.00
47.00	1.8504	310	459	4	A35047.0	6,715.00
48.00	1.8898	321	470	4	A35048.0	7,120.00
50.00	1.9685	321	470	4	A35050.0	7,570.00
