＠：经销品牌>>DORMER>>DORMER钻头>>A125-英国多马DORMER钻头

DORMER

A125

小于2.2 mm 和 5/64" 为光亮
d1(inch) d1(mm) d1(inch) l2(mm) l1(mm) 订货号 　 RMB未税面价
　 1.40 0.0551 100 160 A1251.4X160 　 279.00
　 1.50 0.0591 80 125 A1251.5X125 　 159.00
　 1.50 0.0591 100 160 A1251.5X160 　 188.00
1/16 1.59 0.0625 80 125 A1251/16X125 　 194.00
1/16 1.59 0.0625 100 160 A1251/16X160 　 232.00
　 1.80 0.0709 100 160 A1251.8X160 　 244.00
5/64 1.98 0.0781 80 125 A1255/64X125 　 229.00
5/64 1.98 0.0781 100 160 A1255/64X160 　 239.00
　 2.00 0.0787 80 125 A1252.0X125 　 123.00
　 2.00 0.0787 100 160 A1252.0X160 　 144.00
　 2.20 0.0866 100 160 A1252.2X160 　 150.00
3/32 2.38 0.0938 80 125 A1253/32X125 　 133.00
3/32 2.38 0.0938 100 160 A1253/32X160 　 145.00
　 2.50 0.0984 80 125 A1252.5X125 　 116.00
　 2.50 0.0984 100 160 A1252.5X160 　 143.00
7/64 2.78 0.1094 80 125 A1257/64X125 　 140.00
7/64 2.78 0.1094 100 160 A1257/64X160 　 215.00
　 3.00 0.1181 100 160 A1253.0X160 　 136.00
　 3.00 0.1181 150 200 A1253.0X200 　 181.00
　 3.00 0.1181 200 250 A1253.0X250 　 230.00
1/8 3.18 0.1252 100 160 A1251/8X160 　 167.00
1/8 3.18 0.1252 150 200 A1251/8X200 　 170.00
1/8 3.18 0.1252 200 250 A1251/8X250 　 330.00
1/8 3.18 0.1252 250 310 A1251/8X315 　 380.00
　 3.30 0.1299 100 160 A1253.3X160 　 196.00
　 3.50 0.1378 100 160 A1253.5X160 　 138.00
　 3.50 0.1378 150 200 A1253.5X200 　 170.00
　 3.50 0.1378 200 250 A1253.5X250 　 240.00
9/64 3.57 0.1406 100 160 A1259/64X160 　 242.00
9/64 3.57 0.1406 150 200 A1259/64X200 　 243.00
9/64 3.57 0.1406 250 310 A1259/64X315 　 352.00
5/32 3.97 0.1563 100 160 A1255/32X160 　 169.00
5/32 3.97 0.1563 150 200 A1255/32X200 　 200.00
5/32 3.97 0.1563 200 250 A1255/32X250 　 387.00
5/32 3.97 0.1563 250 310 A1255/32X315 　 491.00
　 4.00 0.1575 100 160 A1254.0X160 　 138.00
　 4.00 0.1575 150 200 A1254.0X200 　 178.00
　 4.00 0.1575 200 250 A1254.0X250 　 239.00
　 4.00 0.1575 250 310 A1254.0X315 　 296.00
11/64 4.37 0.1719 100 160 A12511/64X160 　 223.00
11/64 4.37 0.1719 150 200 A12511/64X200 　 268.00
11/64 4.37 0.1719 250 310 A12511/64X315 　 387.00
　 4.50 0.1772 100 160 A1254.5X160 　 161.00
　 4.50 0.1772 150 200 A1254.5X200 　 210.00
　 4.50 0.1772 200 250 A1254.5X250 　 323.00
　 4.50 0.1772 250 310 A1254.5X315 　 353.00
3/16 4.76 0.1875 100 160 A1253/16X160 　 163.00
3/16 4.76 0.1875 150 200 A1253/16X200 　 186.00
3/16 4.76 0.1875 200 250 A1253/16X250 　 236.00
3/16 4.76 0.1875 250 310 A1253/16X315 　 345.00
3/16 4.76 0.1875 300 400 A1253/16X400 　 653.00
　 5.00 0.1969 100 160 A1255.0X160 　 156.00
　 5.00 0.1969 150 200 A1255.0X200 　 206.00
　 5.00 0.1969 200 250 A1255.0X250 　 255.00
　 5.00 0.1969 250 310 A1255.0X315 　 354.00
　 5.00 0.1969 300 400 A1255.0X400 　 451.00
13/64 5.16 0.2031 150 200 A12513/64X200 　 320.00
13/64 5.16 0.2031 200 250 A12513/64X250 　 414.00
13/64 5.16 0.2031 250 310 A12513/64X315 　 544.00
　 5.50 0.2165 150 200 A1255.5X200 　 190.00
　 5.50 0.2165 200 250 A1255.5X250 　 308.00
　 5.50 0.2165 250 310 A1255.5X315 　 487.00
7/32 5.56 0.2188 150 200 A1257/32X200 　 248.00
7/32 5.56 0.2188 200 250 A1257/32X250 　 316.00
7/32 5.56 0.2188 250 310 A1257/32X315 　 491.00
15/64 5.95 0.2344 150 200 A12515/64X200 　 383.00
15/64 5.95 0.2344 200 250 A12515/64X250 　 473.00
15/64 5.95 0.2344 250 310 A12515/64X315 　 368.00
　 6.00 0.2362 150 200 A1256.0X200 　 221.00
　 6.00 0.2362 200 250 A1256.0X250 　 296.00
　 6.00 0.2362 250 310 A1256.0X315 　 368.00
　 6.00 0.2362 300 400 A1256.0X400 　 536.00
1/4 6.35 0.2500 150 200 A1251/4X200 　 242.00
1/4 6.35 0.2500 200 250 A1251/4X250 　 307.00
1/4 6.35 0.2500 250 310 A1251/4X315 　 380.00
1/4 6.35 0.2500 300 400 A1251/4X400 　 778.00
1/4 6.35 0.2500 400 460 A1251/4X500 　 1,080.00
　 6.50 0.2559 150 200 A1256.5X200 　 254.00
　 6.50 0.2559 200 250 A1256.5X250 　 314.00
　 6.50 0.2559 250 310 A1256.5X315 　 454.00
17/64 6.75 0.2656 150 200 A12517/64X200 　 313.00
17/64 6.75 0.2656 200 250 A12517/64X250 　 421.00
17/64 6.75 0.2656 400 460 A12517/64X500 　 1,080.00
　 7.00 0.2756 150 200 A1257.0X200 　 273.00
　 7.00 0.2756 200 250 A1257.0X250 　 349.00
　 7.00 0.2756 250 310 A1257.0X315 　 493.00
9/32 7.14 0.2813 150 200 A1259/32X200 　 493.00
9/32 7.14 0.2813 200 250 A1259/32X250 　 581.00
9/32 7.14 0.2813 250 310 A1259/32X315 　 778.00
9/32 7.14 0.2813 400 460 A1259/32X500 　 1,080.00
　 7.50 0.2953 150 200 A1257.5X200 　 328.00
　 7.50 0.2953 200 250 A1257.5X250 　 395.00
　 7.50 0.2953 250 310 A1257.5X315 　 512.00
19/64 7.54 0.2969 250 310 A12519/64X315 　 515.00
19/64 7.54 0.2969 400 460 A12519/64X500 　 1,080.00
5/16 7.94 0.3125 150 200 A1255/16X200 　 310.00
5/16 7.94 0.3125 200 250 A1255/16X250 　 390.00
5/16 7.94 0.3125 250 310 A1255/16X315 　 517.00
5/16 7.94 0.3125 300 400 A1255/16X400 　 1,090.00
5/16 7.94 0.3125 400 460 A1255/16X500 　 1,280.00
　 8.00 0.3150 200 250 A1258.0X250 　 386.00
　 8.00 0.3150 250 310 A1258.0X315 　 520.00
　 8.00 0.3150 300 400 A1258.0X400 　 656.00
21/64 8.33 0.3281 250 310 A12521/64X315 　 955.00
21/64 8.33 0.3281 400 460 A12521/64X500 　 1,285.00
　 8.50 0.3346 200 250 A1258.5X250 　 528.00
　 8.50 0.3346 250 310 A1258.5X315 　 707.00
11/32 8.73 0.3438 200 250 A12511/32X250 　 505.00
11/32 8.73 0.3438 250 310 A12511/32X315 　 862.00
11/32 8.73 0.3438 300 400 A12511/32X400 　 1,070.00
11/32 8.73 0.3438 400 460 A12511/32X500 　 1,280.00
　 9.00 0.3543 200 250 A1259.0X250 　 457.00
　 9.00 0.3543 250 310 A1259.0X315 　 582.00
　 9.00 0.3543 300 400 A1259.0X400 　 837.00
23/64 9.13 0.3594 250 310 A12523/64X315 　 1,100.00
23/64 9.13 0.3594 400 460 A12523/64X500 　 1,280.00
　 9.50 0.3740 200 250 A1259.5X250 　 548.00
　 9.50 0.3740 250 310 A1259.5X315 　 739.00
3/8 9.52 0.3750 200 250 A1253/8X250 　 498.00
3/8 9.52 0.3750 250 310 A1253/8X315 　 632.00
3/8 9.52 0.3750 300 400 A1253/8X400 　 799.00
3/8 9.52 0.3750 400 460 A1253/8X500 　 1,100.00
25/64 9.92 0.3906 250 310 A12525/64X315 　 587.00
25/64 9.92 0.3906 400 460 A12525/64X500 　 1,280.00
　 10.00 0.3937 200 250 A12510.0X250 　 526.00
　 10.00 0.3937 250 310 A12510.0X315 　 655.00
　 10.00 0.3937 300 400 A12510.0X400 　 963.00
13/32 10.32 0.4063 200 250 A12513/32X250 　 657.00
13/32 10.32 0.4063 250 310 A12513/32X315 　 811.00
13/32 10.32 0.4063 400 460 A12513/32X500 　 1,310.00
　 10.50 0.4134 200 250 A12510.5X250 　 656.00
　 10.50 0.4134 250 310 A12510.5X315 　 851.00
　 10.50 0.4134 300 400 A12510.5X400 　 1,020.00
27/64 10.72 0.4219 250 310 A12527/64X315 　 851.00
　 11.00 0.4331 200 250 A12511.0X250 　 593.00
　 11.00 0.4331 250 310 A12511.0X315 　 754.00
　 11.00 0.4331 300 400 A12511.0X400 　 942.00
7/16 11.11 0.4375 200 250 A1257/16X250 　 727.00
7/16 11.11 0.4375 250 310 A1257/16X315 　 920.00
7/16 11.11 0.4375 300 400 A1257/16X400 　 1,910.00
7/16 11.11 0.4375 400 460 A1257/16X500 　 1,310.00
29/64 11.51 0.4531 250 310 A12529/64X315 　 851.00
29/64 11.51 0.4531 400 460 A12529/64X500 　 1,310.00
15/32 11.91 0.4688 200 250 A12515/32X250 　 1,055.00
15/32 11.91 0.4688 250 310 A12515/32X315 　 1,415.00
15/32 11.91 0.4688 400 460 A12515/32X500 　 1,310.00
　 12.00 0.4724 200 250 A12512.0X250 　 694.00
　 12.00 0.4724 250 310 A12512.0X315 　 809.00
　 12.00 0.4724 300 400 A12512.0X400 　 1,090.00
31/64 12.30 0.4844 250 310 A12531/64X315 　 851.00
31/64 12.30 0.4844 400 460 A12531/64X500 　 1,345.00
1/2 12.70 0.5000 200 250 A1251/2X250 　 847.00
1/2 12.70 0.5000 250 310 A1251/2X315 　 1,080.00
1/2 12.70 0.5000 300 400 A1251/2X400 　 1,415.00
1/2 12.70 0.5000 400 460 A1251/2X500 　 2,395.00
　 13.00 0.5118 250 310 A12513.0X315 　 868.00
　 13.00 0.5118 300 400 A12513.0X400 　 1,100.00
33/64 13.10 0.5156 250 310 A12533/64X315 　 868.00
33/64 13.10 0.5156 400 460 A12533/64X500 　 1,345.00
17/32 13.49 0.5313 250 310 A12517/32X315 　 868.00
17/32 13.49 0.5313 400 460 A12517/32X500 　 1,345.00
35/64 13.89 0.5469 250 310 A12535/64X315 　 868.00
35/64 13.89 0.5469 400 460 A12535/64X500 　 1,345.00
　 14.00 0.5512 250 310 A12514.0X315 　 1,025.00
　 14.00 0.5512 300 400 A12514.0X400 　 1,205.00
9/16 14.29 0.5625 250 310 A1259/16X315 　 1,025.00
9/16 14.29 0.5625 400 460 A1259/16X500 　 1,380.00
37/64 14.68 0.5781 250 310 A12537/64X315 　 1,025.00
19/32 15.08 0.5938 250 310 A12519/32X315 　 1,025.00
19/32 15.08 0.5938 400 460 A12519/32X500 　 1,380.00
39/64 15.48 0.6094 250 310 A12539/64X315 　 1,025.00
39/64 15.48 0.6094 400 460 A12539/64X500 　 1,380.00
5/8 15.88 0.6250 250 310 A1255/8X315 　 1,025.00
5/8 15.88 0.6250 400 460 A1255/8X500 　 1,380.00
21/32 16.67 0.6563 250 310 A12521/32X315 　 1,025.00
21/32 16.67 0.6563 400 460 A12521/32X500 　 1,380.00
11/16 17.46 0.6875 250 310 A12511/16X315 　 1,025.00
11/16 17.46 0.6875 400 460 A12511/16X500 　 1,415.00
23/32 18.26 0.7188 250 310 A12523/32X315 　 1,050.00
23/32 18.26 0.7188 400 460 A12523/32X500 　 1,415.00
3/4 19.05 0.7500 250 310 A1253/4X315 　 1,050.00
3/4 19.05 0.7500 400 460 A1253/4X500 　 1,415.00
25/32 19.84 0.7813 400 460 A12525/32X500 　 1,415.00
13/16 20.64 0.8125 400 460 A12513/16X500 　 1,415.00
7/8 22.22 0.8750 400 460 A1257/8X500 　 1,450.00
15/16 23.81 0.9375 400 460 A12515/16X500 　 1,450.00
1" 25.40 1.0000 400 460 A1251X500 　 1,450.00
　

DORMER
