＠：经销品牌>>DORMER>>DORMER钻头>>A124-英国多马DORMER钻头

DORMER

A124

四后面型钻尖的焊接硬质合金式短型钻头,扁尾符合 DIN 1809
d1(mm) d1(inch) l2(mm) l1(mm) 订货号 　 RMB未税面价
3.00 0.1181 20 50 A1243.0 　 254.00
3.20 0.1260 25 56 A1243.2 　 285.00
3.50 0.1378 25 56 A1243.5 　 242.00
4.00 0.1575 25 56 A1244.0 　 220.00
4.20 0.1654 28 63 A1244.2 　 262.00
4.50 0.1772 28 63 A1244.5 　 213.00
4.80 0.1890 28 63 A1244.8 　 226.00
5.00 0.1969 28 63 A1245.0 　 229.00
5.20 0.2047 32 71 A1245.2 　 348.00
5.50 0.2165 32 71 A1245.5 　 249.00
5.80 0.2283 32 71 A1245.8 　 255.00
6.00 0.2362 32 71 A1246.0 　 267.00
6.50 0.2559 32 71 A1246.5 　 235.00
6.80 0.2677 40 80 A1246.8 　 254.00
7.00 0.2756 40 80 A1247.0 　 261.00
7.50 0.2953 40 80 A1247.5 　 251.00
8.00 0.3150 40 80 A1248.0 　 253.00
8.50 0.3346 50 90 A1248.5 　 309.00
9.00 0.3543 50 90 A1249.0 　 275.00
9.50 0.3740 50 90 A1249.5 　 352.00
10.00 0.3937 56 100 A12410.0 　 360.00
10.50 0.4134 56 100 A12410.5 　 402.00
11.00 0.4331 56 100 A12411.0 　 366.00
11.50 0.4528 63 112 A12411.5 　 457.00
12.00 0.4724 63 112 A12412.0 　 417.00
13.00 0.5118 63 112 A12413.0 　 606.00
14.00 0.5512 71 125 A12414.0 　 659.00
15.00 0.5906 71 125 A12415.0 　 787.00
16.00 0.6299 80 140 A12416.0 　 946.00
　
