＠：经销品牌>>DORMER>>DORMER板牙>>F330-英国多马DORMER板牙

DORMER

F330

UNF 可调节板牙
UNF TPI d1(mm) d2(mm) h1(mm) 订货号 　 RMB未税面价
4 48 2.85 13/16 1/4 F3304-48X13/16 　 401.00
5 44 3.18 13/16 1/4 F3305-44X13/16 　 401.00
6 40 3.51 13/16 1/4 F3306-40X13/16 　 401.00
8 36 4.17 13/16 1/4 F3308-36X13/16 　 401.00
10 32 4.83 13/16 1/4 F33010-32X13/16 　 401.00
10 32 4.83 1" 3/8 F33010-32X1 　 426.00
12 28 5.49 13/16 1/4 F33012-28X13/16 　 401.00
1/4 28 6.35 13/16 1/4 F3301/4X13/16 　 318.00
1/4 28 6.35 1" 3/8 F3301/4X1 　 376.00
1/4 28 6.35 1.1/2 1/2 F3301/4X1.1/2 　 835.00
5/16 24 7.94 1" 3/8 F3305/16X1 　 376.00
5/16 24 7.94 1.5/16 7/16 F3305/16X1.5/16 　 676.00
5/16 24 7.94 1.1/2 1/2 F3305/16X1.1/2 　 835.00
3/8 24 9.53 1" 3/8 F3303/8X1 　 376.00
3/8 24 9.53 1.5/16 7/16 F3303/8X1.5/16 　 549.00
3/8 24 9.53 1.1/2 1/2 F3303/8X1.1/2 　 835.00
7/16 20 11.11 1" 3/8 F3307/16X1 　 426.00
7/16 20 11.11 1.5/16 7/16 F3307/16X1.5/16 　 549.00
7/16 20 11.11 1.1/2 1/2 F3307/16X1.1/2 　 835.00
1/2 20 12.70 1.5/16 7/16 F3301/2X1.5/16 　 549.00
1/2 20 12.70 1.1/2 1/2 F3301/2X1.1/2 　 645.00
9/16 18 14.29 1.5/16 7/16 F3309/16X1.5/16 　 549.00
9/16 18 14.29 1.1/2 1/2 F3309/16X1.1/2 　 645.00
5/8 18 15.88 1.1/2 1/2 F3305/8X1.1/2 　 645.00
5/8 18 15.88 2" 5/8 F3305/8X2 　 953.00
3/4 16 19.05 1.1/2 1/2 F3303/4X1.1/2 　 645.00
3/4 16 19.05 2" 5/8 F3303/4X2 　 953.00
7/8 14 22.23 2" 5/8 F3307/8X2 　 953.00
1" 12 25.40 2" 5/8 F3301X2 　 953.00
1.1/8 12 28.58 3" 7/8 F3301.1/8X3 　 2,080.00
1.1/4 12 31.75 3" 7/8 F3301.1/4X3 　 2,080.00
1.1/2 12 38.10 3" 7/8 F3301.1/2X3 　 2,080.00
　
