＠：经销品牌>>DORMER>>DORMER锪钻>>G136-英国多马DORMER锪钻

DORMER

G136

锪钻 - 90°
d max(mm) d min(mm) l2(mm) l1(mm) d2(mm) z 订货号 　 RMB未税面价
4.3 1.3 4.0 40 4 3 G1364.3 　 177.00
5.0 1.5 4.5 40 4 3 G1365.0 　 162.00
5.3 1.5 4.5 40 4 3 G1365.3 　 176.00
5.8 1.5 5.0 45 5 3 G1365.8 　 193.00
6.0 1.5 5.0 45 5 3 G1366.0 　 171.00
6.3 1.5 5.5 45 5 3 G1366.3 　 185.00
7.0 1.8 5.5 50 6 3 G1367.0 　 190.00
7.3 1.8 6.1 50 6 3 G1367.3 　 172.00
8.0 2.0 6.1 50 6 3 G1368.0 　 205.00
8.3 2.0 6.5 50 6 3 G1368.3 　 195.00
9.4 2.2 7.2 50 6 3 G1369.4 　 189.00
10.0 2.5 7.6 50 6 3 G13610.0 　 237.00
10.4 2.5 7.6 50 6 3 G13610.4 　 224.00
11.5 2.8 8.0 56 8 3 G13611.5 　 231.00
12.4 2.8 8.5 56 8 3 G13612.4 　 252.00
13.4 2.9 9.0 56 8 3 G13613.4 　 254.00
15.0 3.2 9.5 60 10 3 G13615.0 　 283.00
16.5 3.2 10.5 60 10 3 G13616.5 　 317.00
19.0 3.5 11.7 63 10 3 G13619.0 　 368.00
20.5 3.5 13.0 63 10 3 G13620.5 　 430.00
23.0 3.8 13.7 67 10 3 G13623.0 　 475.00
25.0 3.8 15.5 67 10 3 G13625.0 　 622.00
26.0 3.8 15.5 67 10 3 G13626.0 　 670.00
28.0 4.0 16.5 71 12 3 G13628.0 　 767.00
30.0 4.2 18.5 71 12 3 G13630.0 　 902.00
31.0 4.2 18.5 71 12 3 G13631.0 　 911.00
　
