＠：经销品牌>>DORMER>>DORMER锪钻>>G125-英国多马DORMER锪钻

DORMER

G125

锪孔 - 180°
d1(mm) d3(mm) M l1(mm) l2(mm) d2(mm) z 订货号 　 RMB未税面价
6.5 2.5 M 3 t 71 14 5.0 3 G1256.5X2.5 1) 233.00
6.5 3.2 M 3 f 71 14 5.0 3 G1256.5X3.2 2) 233.00
6.5 3.4 M 3 m 71 14 5.0 3 G1256.5X3.4 3) 233.00
8.0 3.3 M 4 t 71 14 5.0 3 G1258.0X3.3 1) 216.00
8.0 4.3 M 4 f 71 14 5.0 3 G1258.0X4.3 2) 216.00
8.0 4.5 M 4 m 71 14 5.0 3 G1258.0X4.5 3) 216.00
10.0 4.2 M 5 t 80 18 8.0 3 G12510.0X4.2 1) 233.00
10.0 5.3 M 5 f 80 18 8.0 3 G12510.0X5.3 2) 233.00
10.0 5.5 M 5 m 80 18 8.0 3 G12510.0X5.5 3) 233.00
11.0 5.0 M 6 t 80 18 8.0 3 G12511.0X5.0 1) 247.00
11.0 6.4 M 6 f 80 18 8.0 3 G12511.0X6.4 2) 247.00
11.0 6.6 M 6 m 80 18 8.0 3 G12511.0X6.6 3) 247.00
15.0 6.8 M 8 t 100 22 12.5 3 G12515.0X6.8 1) 400.00
15.0 8.4 M 8 f 100 22 12.5 3 G12515.0X8.4 2) 400.00
15.0 9.0 M 8 m 100 22 12.5 3 G12515.0X9.0 3) 400.00
18.0 8.5 M 10 t 100 22 12.5 3 G12518.0X8.5 1) 486.00
18.0 10.5 M 10 f 100 22 12.5 3 G12518.0X10.5 2) 486.00
18.0 11.0 M 10 m 100 22 12.5 3 G12518.0X11.0 3) 486.00
20.0 10.2 M 12 t 100 22 12.5 3 G12520.0X10.2 1) 516.00
20.0 13.0 M 12 f 100 22 12.5 3 G12520.0X13.0 2) 516.00
20.0 13.5 M 12 m 100 22 12.5 3 G12520.0X13.5 3) 516.00
1) t = 用于攻丝底孔 2) f = 用于通孔的精加工 3) m = 用于通孔的半精加工
　
